Water full-bore ball valve, standard series, with sealable cap FEMALE-FEMALE

Application WATER

VALVES
Full-bore ball valves
Full

Code	Kg	Box	Master Box	L	L1	A1	A2	Combinazione	Q	H1	ØH2	ØP	Lc	Ch1	Ch2	Ch3	PN-MOP	Kv	PCP	cod.	A3	NA	NA
65885900050	0,21	0,21	100	56	15	Rp1/2	0	F-F	12x23	42	32	15	28	ott.25	0	0	PN50	0	0	0	0	0	F generica
65885900075	0,34	0,34	96	66	16,3	Rp3/4	0	F-F	12x23	49	40	20	33	ott.32	0	0	PN40	0	0	0	0	0	F generica
65885900100	0,6	0,6	60	80	19,1	Rp1	0	F-F	12x25	53,5	50	25	40	ott.38.5	0	0	PN40	0	0	0	0	0	F generica
65885900125	0,79	0,79	40	91	21,4	Rp1.1/4	-	F-F	12x25	61,5	60	32	45,5	ott.48	-	-	PN32	-	-	-	-	-	F generica
65885900150	1,26	1,26	24	103	21,4	Rp1.1/2	0	F-F	12x25	74,5	74	40	51,5	ott.55	0	0	PN32	0	0	0	0	0	F generica
65885900200	1,82	1,82	16	123	25,7	Rp2	0	F-F	12x25	81	89	50	61,5	ott.67	0	0	PN25	0	0	0	0	0	F generica
65885900250	3,4	3,4	8	148	30,2	Rp2.1/2	0	F-F	0	99	0	63	0	0	0	0	PN25	0	0	0	0	0	F generica
65885900300	5,7	5,7	2	171	33,3	Rp3	-	F-F	16	116	0	76	0	-	-	-	PN25	-	-	-	-	-	F generica
